Hot Sale LCD 15A 12V/24V Autoswitch Solar Panel Battery Regulator Charge Controller CE APJ |

Hot Sale LCD 15A 12V/24V Autoswitch Solar Panel Battery Regulator Charge Controller CE APJ |

Protection:

1. over-load protection

5. over-charging protection

6. reverse polarity protection

Installation Instructions:

Open the top cover of controller and connect the wire with terminals as the diagram on the top cover of it.

1.Connect the "+","-" poles of the battery to the corresponding ports of controller (the third and the fourth one from left).

2.Connect the "+","-" poles of the solar pannel to the corresponding ports of controller (the first and the second one from left).

3.Connect the "+","-" poles of the load to the corresponding ports of controller (the fifth and the sixth one from left).

Note: If there is connection error, it may damage your controller.

Status instruction:

The charge indicator: While charging, the charge indicator will be green light ON. When the battery indicator is flashing uninterruptedly, it means the battery is full charge and the system enters into intelligent protective charging.

Battery voltage display screen: the battery voltage will display only when the battery power is normal.

Battery under voltage display: when the battery is in the state of under voltage , (in the 12V system the battery voltage is less than 12V, in the 24V system the battery voltage is less than20V), a middle cross of the digital tube flickers as is shows in the figure.

Parameters:

Package Includes:

1x Solar charge controller

1x English User manual
